Roadmachine FOUR
$4,199.00
$4,199.00
Free Bike Adjustments for 6 Months
Six months of free bike adjustments are included with the cost of any new bike. Plus, get 50% off the bike fit of your choice!
Article #100267082005
Description
The Roadmachine brings big tire capabilities to its proven endurance platform to make every ride better. Built with Shimano’s 105 Di2 groupset and fitted with road-smoothing 30mm tires on a set of Mavic Open Disc wheels, the Roadmachine FOUR also features many of our innovative technologies, such as a Premium Carbon D-Shape seatpost to ensure next-level compliance and integrated downtube storage for peace of mind.
- Shimano 105 Di2 Drivetrain
- Mavic Open Disc Wheelset
- Carbon D-Shape Seatpost
Specifications are subject to change without notice. All bike and frame weights are based off pre-production painted frames. Weights may vary in final production.
-
Brakes
SHIMANO 105 -
Crank
SHIMANO 105 -
Drivetrain
SHIMANO 105 Di2 -
Frame
Roadmachine Carbon -
Wheels
Mavic Open Disc
| Component | Part |
|---|---|
| Frame | Roadmachine Carbon with Tuned Compliance Concept Endurance, Fender Mounts, Integrated Downtube Storage, Stealth Dropout Design, 12 x 142mm Thru-Axle |
| Fork | Roadmachine Carbon with Tuned Compliance Concept Endurance, Fender Mounts, Stealth Dropout Design, Flat Mount Disc, 12 x 100mm Thru-Axle |
| Stem | BMC RSM 01 |
| Handlebar | BMC RAB 03, Ergo Top Shape, Compact Bend |
| Seatpost | Roadmachine Carbon D-Shaped Seatpost, 15mm Offset, D-Fender Compatible |
| Saddle | Fizik Taiga or Selle Royal SRX |
| Crankset | SHIMANO 105 (FC-R7100) |
| Chainrings | 50-34T |
| Cassette | SHIMANO 105 (CS-R7100) |
| Cassette Size | 11-34T |
| Chain | SHIMANO CN-M6100 |
| Front Derailleur | SHIMANO 105 Di2 (FD-R7150) |
| Rear Derailleur | SHIMANO 105 Di2 (RD-R7150) |
| Shifters | SHIMANO 105 Di2 (ST-R7170) |
| Gears | 2 x 12 |
| Bottom Bracket | PF86 Bottom Bracket |
| Brake Levers / Calipers | SHIMANO 105 (BR-R7170) |
| Rotors | SHIMANO SM-RT70 |
| Rotor Size (F/R) | 160 / 140mm |
| Rims | Mavic Open Disc |
| Hubs (F/R) | CL-712 (F), RXC-1425 (R), Thru-Axle |
| Tires | Vittoria Rubino IV G2.0, Tube only, 30mm |
| Tubeless Information | Tubetype Rims, Tubetype Tires |
| Tire Clearance | up to "40mm measured" (frameset clearance) but limited to "34mm measured" by the front derailleur |
| Weight without Pedals | 8.6 kg |
| ASTM Classification | Level 2 |
| System Weight Limit | 110kg |
* Specs subject to change
