Exie Deore
Introducing the Exie for all. Sharing the same geometry and performance as the World Cup winning Exie USA, this newest offering is handbuilt in Vietnam. It’s everything you love about Ibis' US made offering (albeit ~250g heavier) in a wallet-friendly
Introducing the Exie for all. Sharing the same geometry and performance as the World Cup winning Exie USA, this newest offering is handbuilt in Vietnam. It’s everything you love about Ibis' US made offering (albeit ~250g heavier) in a wallet-friendly build.
- Exie’s seat tube angles allows you to harness your strongest muscles, while reducing any potential knee or wrist strain
- dw-link suspension platform offers incredible climbing efficiency and traction along with plush, downhill-crushing goodness
- The Exie has clearance for two water bottles inside the front triangle on every size frame
Specifications are subject to change without notice. All bike and frame weights are based off pre-production painted frames. Weights may vary in final production.
Returns & Price Matching
| Component | Part |
|---|---|
| Frame Material | Carbon Fiber |
| Frame Weight | 2340g, 5.15lbs (size medium, w/ shock) |
| Fork | Fox Float 34 Performance Series, Step-Cast, Grip, 120mm, 29', 110x15 |
| Shock | Fox Performance Series Float DPS with EVOL, 190mm x 45mm |
| Wheels | Ibis 933 Aluminum Rims, Ibis Hubs |
| Tires (F/R) | Maxxis Rekon Race 29" x 2.4" Exo/TR WT |
| Brakes | Shimano Deore M6100, 2 Piston |
| Rotors (F/R) | Shimano SM-RT66 180/160 |
| Crankset | Shimano Deore M6120 24mm spindle, 30t Alloy Ring |
| Bottom Bracket | Shimano SM BB52 |
| Rear Derailleur | Shimano Deore M6100, Shadow Plus |
| Shifter | Shimano Deore M6100 |
| Cassette | Shimano Deore M6100, 10-51T |
| Chain | Shimano Deore M6100 |
| Chain Guide | Ibis Top Guide |
| Headset | Cane Creek 40: IS 41/28.6 upper, IS 52/40 lower |
| Grips | Lizard Skin Charger |
| Handlebar | Ibis Aluminum, 780mm |
| Stem | Ibis 31.8mm S/M: 40mm, L/XL: 50mm |
| Seatpost | KS Rage-i Dropper S: 125mm, M: 150mm, L/XL: 170mm |
| Saddle | WTB Silverado, 142mm |
| Wheel Size | 29" / up to 2.4" tires |
| Front Travel | 120mm forks |
| Rear Travel | 100mm (4 inches) |
| Boost Axles | 148mm rear / 110mm front |
| Seatpost Diameter | 31.6mm |
| Rear Brake | 160mm post mount / 180mm max |
| Derailleur Hanger | Universal Derailleur Hanger (UDH) SRAM part number AC-DRHG-MTB-A1 |
| Bottom Bracket | Threaded (73mm English threaded) |
| Chainline | 52mm or 55mm chainline, 168mm Q Factor |
| ISCG 05 Compatible | Integrated Upper Chain Guide |
| Headset | IS 41/28.6 upper, IS 52/40 lower |
* Specs subject to change
